Understanding Film Extrusion: How It WorksFilm extrusion is a continuous manufacturing process where thermoplastic resins are heated, melted, and formed into thin, flexible sheets. The process starts by feeding plastic pellets or granules into a heated barrel equipped with a rotating screw. As the material moves through the barrel, it melts and becomes a uniform, viscous liquid.
Understanding Film Extrusion: How It Works Film extrusion is a continuous manufacturing process where thermoplastic resins are heated, melted, and formed into thin, flexible sheets. The process starts by feeding plastic pellets or granules into a heated barrel equipped with a rotating screw. As the material moves through the barrel, it melts and becomes a uniform, viscous liquid.
The molten plastic is then forced through a specially designed die, which determines the shape and initial thickness of the film. From here, the process diverges into two main methods: blown film extrusion and cast film extrusion.
Cast Film ExtrusionCast film extrusion uses a flat, narrow slot die to produce a wide sheet of molten plastic. This sheet is immediately passed over chilled rollers that rapidly cool and solidify the film. Cast films typically offer superior optical clarity, consistent thickness, and a smoother surface finish compared to blown films. They're ideal for applications requiring high transparency or printability, and that's the manufacturing process used by Achilles USA to produce our plastic films.
What Is Co-Extrusion? Taking Performance to the Next LevelCo-extrusion is an advanced manufacturing process that combines two or more different polymers into a single, unified multilayer film. Unlike lamination, which bonds pre-made layers together after production, co-extrusion creates all layers simultaneously as the film is formed.
Each polymer is melted in its own extruder, then fed into a shared feedblock and die assembly. The materials are carefully layered inside the die and exit as one cohesive structure. This seamless integration eliminates the risk of delamination and contamination that can occur with laminated films.
At Achilles USA, we offer 1 to 5 layer co-extruded plastic film using up to four different materials in a single run. Our cleanroom extrusion capabilities include automated thickness control and in-line optical defect inspection, ensuring precision and consistency across every roll.
