Manifold Assemblies

Integrated fluidic manifolds minimize size and internal volume, reduce the number of potential leak points, and offer the advantage of a drop-in, fully tested solution. At the system level, this reduces risk by decreasing assembly time, operator error, and streamlining preventative maintenance routines. However, designing a manifold with integrated active and passive fluid control components can be challenging. Our expertise in fluidics, the components we supply, and the systems they go into, allow us to seamlessly incorporate our solenoid valves, pumps, check valves, restrictors, and a variety of outsourced components (PCBs, sensors, etc.) into a manifold subassembly with ease. We will work with you to select the optimal manifold manufacturing technique based on your application needs, then we will provide proposal drawings and CAD models for fit verification. Together, we will iterate through the prototype process with machined or 3D printed parts. Our engineering partnership carries through to production-ready assemblies that are 100% functionally tested and ready for install into your system.
